Overview

THE SOLID APPROACH TO TRENCHING.

The Plastibeton® cable trench is a trusted system by power, utility, railroad and transit companies throughout North America to contain, protect and allow easy access to power, control, signal, communication, and fiber optic cables. Made of a unique, patented High-Density Polymer Concrete, the cable trench system offers flexibility and strength, as well as exceptional resistance to freeze/thaw conditions. The Plastibeton® Channel System provides outstanding 16,000 LB load rating at any point. It is designed an tested to exceed industry standards, and with an unmatched strength to weight ratio, Plastibeton® reduces installation costs and is the safer cable trench choice.

Features

A CABLE SYSTEM YOU CAN RELY ON.

Advanced Design

Plastibeton® cable trench contains, protects and allows easy access to power, control, signal, communication, and fiber optic cables. Made of a unique, patented High-Density Polymer Concrete, the Plastibeton® cable trench system offers flexibility and strength, exceptional resistance to freeze/thaw conditions, and provides outstanding 16,000 LB load rating at any point.

Safer and Quicker Access

Our 16K Trench Covers have become even lighter. Oldcastle Infrastructure has developed a new, lightweight polymer concrete technology–reducing cover weight by more than 25%. Our Plastibeton® LW trench covers meet the same load rating and environmental performance that made Plastibeton® the industry leader in vehicle rated cable trench. During installation or maintenance, these lightweight covers allow safer and quicker access to cables.

ENGINEERED

For trusted performance during the most strenuous traffic loadings, turn to the Plastibeton® HD cover. These covers utilize extra reinforcement to double the load rating the typical 16,000 LB load rating. Sometimes referred to as “H40 rated”, these covers are designed for a 32,000 LB wheel load.

Duability for High Traffic Areas

Steel covers are recommended for road crossings with frequent traffic. Our covers are a high-quality, durable galvanized steel and are designed to drop-in to our standard Plastibeton® Cable Trench. They feature a slip-resistant, diamond plate surface. Grated covers are also available in power applications where cable de-rating and heat dissipation is required. They can be placed continuously or at intervals.

Trusted to Protect

By using an advanced composite trench and cover system, Plastibeton® PED delivers a high performing trench system at a lower total install cost than any competition. The covers are designed, tested, and certified to be walked on without compromising safety and the lightweight composition and design makes it easy to install, remove or upgrade.

Plastibeton® Design Guide

Download our Plastibeton® Design Guide for layouts, miters, and transitions and start exceeding industry standards.

Download

Videos

Products

Product Filters
Height FT / IN
Width FT / IN
Length FT / IN
Clear Filters
Name Model Height Width Length Diameter Downloads Quote Generator
Plastibeton® 68 8” 6” 118” View Add
Plastibeton® 128 8” 12” 118” View Add
Plastibeton® 1216 16” 12” 118” View Add
Plastibeton® 2012 12” 20” 118” View Add
Plastibeton® 2016 16” 20” 118” View Add
Plastibeton® 3012 12” 30” 118” View Add
Plastibeton® 3016 16” 30” 118” View Add
Plastibeton® 4016 16” 40” 118” View Add
Plastibeton® C12 Covers 12” 39” View Add
Plastibeton® C20 Covers 20” 39” View Add
Plastibeton® C30 Covers 30” 23.5” View Add
Plastibeton® C40 Covers 40” 23.5” View Add
Plastibeton® C6 Covers 6” 39” View Add
